KORAWALL Optimal WKO
standard wall-mounted design
The KORAWALL wall convectors are a traditional product that has found many satisfied customers worldwide. They excel in modern design, simple installation, economical operation and are suitable for households as well as commercial spaces. The main advantages include high thermal performance even with smaller dimensions. The low surface temperature, which reaches a maximum of 40 °C, ensures safety during use. In addition, there is no heat dissipation into the walls, which contributes to efficient energy use.
-
Heating -
Natural convection
| Height [mm] | 450, 600 mm |
| Width [mm] | 130 mm |
| Length [mm] | 400, 600, 800, 1 000, 1 200, 1 400, 1 600, 1 800, 2 000 mm |
| Heat output [W] | from 163 to 1 919 W |
| Maximální pracovní tlak [MPa] | 1,2 MPa |
| Max. operating temperature | 90 °C |
| Surface temperature | 40 °C According to inlet water temperature |
| Connection thread | internal G ½" |
| Hydraulic connection | bottom (right-side or left-side) |
ORDERING CODES
Example order code: WKO-120/45/13-V1SPSP-10
KORAWALL Optimal WKO wall-mounted convector, length 120 cm, height 45 cm, width 13 cm, sheet metal steel casing white RAL 9016, bottom right connection with standard regulation.
| KORAWALL | Natural convection | Typ | | Length/Height/Width [cm] | | Convector connection | Exchanger colour | Casing materia | Grille type | Connection type | Connection side | | Colour code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| W | K | O | - | 120/45/13 | - | V | 1 | S | P | S | P | - | 10 |
| | | Optimal | | | | counterflow | without colour | steel | perforated | bottom | P - right L - left | 10 RAL 9016 39 matt black RAL 9005 ** RAL - Code 99 other RAL colour |
